These innovations in the new Ranger 8 series once again highlight Steiner's commitment to setting very high standards in the industry. Every product that leaves their company carries the promise of extreme quality, innovation and reliability.
- XL field of view For maximum situational awareness and essential safety in every situation.
- Steiner's high-contrast optics guarantee fast, bright, high-contrast images with high edge-to-edge sharpness and exceptional detail recognition.
- Integrated ballistic turret. The turret allows the shooter to reliably and accurately compensate for falling bullets at different distances. Using 4 different numbered rings, the shooter can set marks for preferred distances.
- Improved light transmission. Light transmission of over 92% guarantees bright images even in the most difficult lighting conditions.
- Zero mode. The elevation turret can always be reliably reset to 0, especially for dark environments and rapid target acquisition.
- Elegance, lightness and aesthetic design. The one-piece tubular bodies are coated with a satin-finished, scratch-resistant hard anodising conforming to military standards and, thanks to smooth transitions and elegant shapes, offer sufficient space for mounting accessories.
- Fibre optic reticle. The crystalline red dot can be precisely adjusted in any lighting situation.
CONSTRUCTION FEATURES
Item number: 3004904704
Effective objective lens diameter: 56 mm - 34 mm
Magnification min. /max.: 4x / 32x
Weight: 774g
Length : 385 mm
Operating range: -25°C bis +63°C
Exit pupil: 8,5 mm - 1,7 mm
Field of view at 100m: 9,46 m - 1,18 m
Eye relief: 95 mm
Dioptre compensation: -3 / +2
Parallax-free: 20m(y) to infinity
Reticle: 4-AI fiber dot
Reticle position: 2nd focal plane
Reticle adjustment per click at 100m: 1 cm / 100 m
Max. adjustment of elevation / windage at 100m: +/- 115 cm
Center tube diameter: 30 mm
Objective tube diameter: 64 mm
Reticle illumination: 11 levels (5x day, 6x night) with OFF position between the levels, 6h Auto-Off
High-performance optics: High Contrast
Waterpressure resistance: 1m
STEINER nitrogen filling: Yes
Accessories: flip up covers (Obj+Oc)
