These innovations in the new Ranger 8 series once again highlight Steiner's commitment to setting very high standards in the industry. Every product that leaves their company carries the promise of extreme quality, innovation and reliability.
- XL field of view For maximum situational awareness and essential safety in every situation.
- Steiner's high-contrast optics guarantee fast, bright, high-contrast images with high edge-to-edge sharpness and exceptional detail recognition.
- Integrated ballistic turret. The turret allows the shooter to reliably and accurately compensate for falling bullets at different distances. Using 4 different numbered rings, the shooter can set marks for preferred distances.
- Improved light transmission. Light transmission of over 92% guarantees bright images even in the most difficult lighting conditions.
- Zero mode. The elevation turret can always be reliably reset to 0, especially for dark environments and rapid target acquisition.
- Elegance, lightness and aesthetic design. The one-piece tubular bodies are coated with a satin-finished, scratch-resistant hard anodising conforming to military standards and, thanks to smooth transitions and elegant shapes, offer sufficient space for mounting accessories.
- Fibre optic reticle. The crystalline red dot can be precisely adjusted in any lighting situation.
CONSTRUCTION FEATURES
- Article number: 3003904704
- Effective lens diameter: 56 mm - 33 mm
- Min./max. magnification: 3x / 24x
- Weight: 774 g
- Length: 375 mm
- Operating range: -25°C to +63°C
- Output pupil: 8.5 mm - 2.3 mm
- Field of view at 100 m: 12.6 m - 1.6 m
- Eye relief: 95 mm
- Dioptric compensation: -3 / +2
- Parallax-free: 20m(y) at infinity
- Reticle: 4-AI fibre dot
- Reticle position: 2nd focal plane
- Reticle adjustment per click at 100m: 1 cm / 100 m
- Maximum elevation/deviation adjustment at 100m: +/- 115 cm
- Centre tube diameter: 30 mm
- Objective tube diameter: 64 mm
- Reticle illumination: 11 levels (5x day, 6x night) with OFF position between levels, 6h Auto-Off
- High-performance optics: High contrast
- Water resistance: 1m
- STEINER nitrogen filling: Yes
- Accessories: flip-up covers (Obj+Oc)
