XL Field of View For maximum situational awareness and essential safety in every situation. This optic guarantees fast, bright, high-contrast images with high edge-to-edge sharpness and exceptional detail recognition.
- Integrated ballistic turret (BT). The turret allows the shooter to reliably and accurately compensate for bullet drop at different distances. Using 4 different numbered rings, the shooter can set marks for preferred distances.
- Improved light transmission. Light transmission is over 92%, ensuring bright images even in the most difficult lighting conditions.
- Zero mode. The elevation turret can always be reliably reset to 0, especially for dark environments and rapid target acquisition.
- Elegance, lightness and aesthetic design. The one-piece tubular bodies are coated with a satin-finish, scratch-resistant hard anodising to military standards and, thanks to smooth transitions and elegant shapes, offer sufficient space for mounting accessories.
- Fibre dot reticle. The crystalline red dot can be precisely adjusted to any lighting situation.
TECHNICAL SPECIFICATIONS
Effective lens diameter: 50 mm - 14 mm
Minimum / maximum magnification: 2x / 16x
Weight: 684 g
Length: 345 mm
Operating range: -25°C to +63°C
Eye relief: 8.5 mm - 3.1 mm
Field of view at 100 m: 18.92 m - 2.37 m
Eye relief: 95 mm
Dioptric compensation: -3 / +2
Parallax-free: 20m(y) at infinity
Reticle: 4-AI fibre dot
Reticle position: 2nd focal plane
Reticle adjustment per click at 100m: 1 cm / 100 m
Maximum elevation/forward adjustment at 100m: +/- 160 cm
Centre tube diameter: 30 mm
Objective tube diameter: 57 mm
Reticle illumination: 11 levels (5x day, 6x night) with OFF position between levels, 6h Auto-Off
High-performance optics High contrast
Water resistance: 1m
STEINER nitrogen filling: Yes
