Lens options each with 100mm of eye relief, a wide field of view, there is a rubber eyepiece to provide concealed observation at night; Keeping the user's habit of using traditional daytime optic. Clear field of view. Longer, more enjoyable viewing.
Targets can be detected up to 1000m away. The newly developed compact ranging laser module is precise and has fast detection speed. When paired with integrated ballistics, the LRF gives you the range information you need at night to hunt smarter. Precise target ranging.
800*800 IPS Ultra-clear Display. The thermal image can be displayed on the display with the picture-in-picture (PIP) function providing a clear heat signature, greatly improve the comfort of eye observation. Higher image quality, Reduced visual fatigue.
Circular display design allows for seeing a whole circle of image. With a wide field of view (FOV), centering setting of the crosshair after zeroing, helping you with a great sense of where the target is in relation to the environment.
Featuring a 384x288 pixel resolution and 12μm vanadium oxide (vox) sensor, NETD ≤25mK and 12µm pixel pitch allows users to enjoy rich contrast and bold resolution when acquiring targets. Thermal images with high contrast, Extreme sensitivity, Enhanced identification of targets.
The integrated ballistics calculator can calculate bullet trajectory parameters such as velocity, bullet weight and zero range. Improve your accuracy by calculating precise aiming points for the next shot. Quickly display the exact aiming point, Precise placement of your shot.
45mm optical objective lens available lens brings the hunter a wide field of view. Suitable for various hunting environments; the smaller the field of view, the further you can see. Precise target acquisition, Hunt smarter.
The TS3x uses proprietary software and a next-generation image enhancement algorithm to achieve high sensitivity values for the infrared spectrum and improve the visibility of the image. The IREA algorithm improves the overall image by reducing image distortion and increasing detail, even for distant targets. Improved detection of targets, Reduced image distortion, Images without delay.
Specs:
- Model: TS31
- Type: Uncooled VOx(vanadium oxide)
- Resolution(px): 384*288
- Pixel size(µm): 12*12
- NETD(mK): ≤35mK
- Frame rate(Hz): 50
- Human detection distance(m): 1700
- Vehicle detection distance(m): 3000
- Objective Lens(mm): 45
- Optical Magnification(x): 1.7/2.2/3/4
- Digital Zoom(x): 2/4/6
- Field of view (HxV): Horizontal5.6° - Vertical 5.6° - Diagonal 8°
- Eye Relief(mm): 100
- Diopter Adjustment(D): -3D~+5D
- LRF: yes
